The inability to access data, run simple reports and develop new software and systems can be infuriating. Often, the root cause is fragmentation of data in multiple “data silos.” Unfortunately, the cure for data silos can be worse than the disease. Enterprise data lakes or warehouse projects, for example, are prone to becoming overgrown and unmanageable.

Three new data integration techniques offer hope of making things easier.

1. Data lakes
When you move all your data from disparate silos into one system – such as Hadoop – you create a data lake. Data lakes are easy to implement, highly flexible and moderately powerful. Unfortunately, they are hard to govern.

2. Virtual databases
Virtual databases, also known as federated databases, are single systems comprising multiple data sets that act as one big database. Under the covers, a virtual database queries the back-end systems and converts the data into a common format in memory. Unfortunately, that can take a lot of processing power and can cost a great deal of money.

3. Data hubs
This is a hub-and-spoke approach to data integration in which data is physically moved to a central location and re-indexed. Like data lakes, hubs are new systems. Unlike data lakes, data hubs are also operational, so they can support transactional workloads and discovery as well as analytics.

A framework for understanding

The three new approaches can be categorized in terms how they move, harmonize and index data. Each has its advantages, which are summarized here.

Let’s look at each in more detail.

Data movement

This provides for operational – and organizational – separation from source systems. Hubs and lakes both move data. The data from each silo is copied to a new set of disks and processed by a new set of servers and software. The benefits of having a separate data store that doesn’t hit your production servers for every lookup are substantial. In contrast, a virtual (federated) database delegates queries to each source system for each query because data does not move.
The problem is that copies of data lag behind the master systems. There are workarounds like the Lambda architecture or streaming changes, but data freshness must be considered.

Data harmonization

All data must eventually be harmonized or it is nearly useless. A simple summation like “total sales per region” must access sales data in all formats, and normalize them for currency differences, postal codes and other factors. Data hubs harmonize early, federations harmonize late, and data lakes harmonize in an ad-hoc, ungoverned way.

Harmonization falls into three categories of varying computational difficulty: naming differences, which are simple matters of terminology; structural differences in the schemas storing the source data; and semantic differences where the values themselves are incompatible.

Harmonization is one of the most important factors in determining the success of a data integration project. The process should be well-governed, and the harmonized data should be indexed for efficient operational use, beyond the simple movement of dis-harmonious source data.

Businesses typically can’t wait for a massive data modeling effort. Instead, they should identify a limited number of critical data elements to harmonize early and fold in new ones over time. A system that can store data as is – such as Hadoop or MarkLogic – is ideal for this.

Data indexing

Indexing enables fast lookup for operational workloads. Unlike batch processes, which have the luxury of scanning every record in a data set, or fast-batch processors like Apache Spark, operational workloads require indexes.

Federated (virtual) databases don’t do any indexing themselves. Instead, they rely on the source silos to have adequate indexing, which is a risky approach. When indexes are missing, federated indexes may fall back to full-scan approaches to satisfy a query.
Data lakes do very little Indexing. When they do, it’s typically by integrating additional components such as mini data marts, Apache Solr text indexes and HBase tables.

Data hubs are distinguished from other approaches by their comprehensive indexing. Data is indexed after it is harmonized, so the indexes are built on top of higher-value data. By moving data, hubs have both a place to store indexes and an infrastructure on which to utilize them.

Applying the three key concepts

In summary, data hubs are the most powerful, fully evolved approach to data integration, but each approach has its place. The key concepts of data movement, harmonization and indexing tell us what tradeoffs we’re making.

For example, large organizations need separate, scalable, reliable infrastructure for integrated data. This requires data movement. Operational loads require sub-second, database-style query, which requires indexing. Federated databases suffer from “least common denominator” query syndrome, and are limited by the weakest integrated system. So, to effectively plan for future growth, choose an approach with its own indexing and movement capabilities.

Focusing on movement, harmonization and indexing will make your decision easier.

Damon Feldman is solutions director at MarkLogic Corp. and a seven-year veteran of the company. He has been involved with some of the largest MarkLogic projects for customers ranging from the US Intelligence Community to HealthCare.gov to private insurance companies.
